Biolase EPIC X Soft Tissue Dental Laser

Key Features of Epic X Diode Laser:

• 940nm superior diode wavelength for faster and precise cutting along with better coagulation.

• Comfort Pulse, a distinctive feature that enhances patient comfort as it prevents overtemperature of surrounding tissues and reduces the risk of “Tissue Charring”.

• “3-in-1” Device that can intelligently help you to choose the surgical procedure from the list of 14 most commonly performed surgeries using a touch screen. Along with this tooth bleaching and pain, therapy makes this a multi-purpose device.

• Faster treatment and 3D healing for patient comfort.

• Total Wireless laser for easy portability between operatories.

• Faster absorption in the targeted tissue and better ablation.

• Brighter smiles and considerable changes in the shade of the tooth with a single-visit tooth whitening procedure in just 20 min chairside time.

• Pre-initiated tips for assurance of lesser time required to do the surgery.

Technical Specifications:

• Dimensions: 14.5 cm x 11.2 cm x 16.5 cm

• Procedures: 14 Pre-Set & 6 customizable

• Operating Voltage: 100V – 240V at 1.5A

• Frequency: 50/60Hz

• Medium: InGaAsP Semi-conductor diode

• Laser Classification: IV

• Wavelength: 940 ± 10nm

• Max Power Output: 10W

• Power Accuracy: ± 20%

• Power Modes: Continuous, Pulse modulation

• Fiber Tips Diameters: 200µm, 300 µm, 400µm

• Pulse Duration: 0.01 ms – 20 ms

• Pulse interval: 0.04 ms – 20 ms

• Pulse repetition Rate: Up to 20 KHz

Spot Size:

• Surgical Handpiece - 400 µm (maximum in contact mode)

• Deep Tissue Handpiece - 30 mm diameter = 7.1 cm2 area

• Whitening Handpiece - Rectangular 35 mm x 8 mm = 2.8 cm2

• NOHD - 4.77 meters

• Beam Divergence - 8 - 22° per side angle

• Standard Fiber Cable Length - 5 feet (1.524 meters)
